Made in USA
Orem, Utah
Lifetime Guarantee
Unconditional
10 Colors
In-house powder coat
Fully Adjustable
0-6" of lift
3 X-Series Options
Only Core 4x4
Product Details
Fits:
- 2018+ Jeep Wrangler JL / JLU
- 20+ Jeep JT Gladiator
- 07-18 Jeep Wrangler JK / JKU
Benefits:
- The vehicle's roll center is raised, reducing body roll and dramatically improving overall handling
- Weld on design for strength and reliability
- Compatible with all lift heights, bracket can be trimmed for track bar bracket heights from stock, 1", 2" +3" over stock height
- Bracket moves track bar closer to the axle centerline to clear aftermarket high-steer knuckles/tie rod at full steering lock
- Takes the place of the very weak factory axle side track bar mount
- Top mount designed to be compatible with the drag link flip
Features:
- Laser cut from 1/4" steel
- Weld on tabs for steering assist rams included
- Weld on sway bar relocation tab included
Notes:
- Must run drag link in high steer configuration, flipped above knuckle, to use this bracket.
- Adjustable front track bar recommended for lifts 3” or higher.
- Minimum of 3” bump stop spacing required.
- Minimum 4.75” wheel backspacing required to clear drag link in flipped position.
| Make | Model | Submodel | Years |
|---|---|---|---|
| Jeep | Gladiator | 2020 - Present | |
| Jeep | Wrangler | 2007 - 2018 | |
| Jeep | Wrangler | 2018 - Present |
| Vehicle | Jeep Gladiator JT (20–Present) or Jeep Wrangler JL / JLU (18–Present) or Jeep Wrangler JK / JKU (07–18) |
| Brand | Synergy |
| Placement on Vehicle | Front |
| Mounting Style | Weld-On |
