16pc Kit

Master Rebuild kit for CMP-J-JL-K16

468.00 468.0 USD 468.00

468.00

Not Available For Sale

More ways to pay ▾

100% bolt-on no welding Expert Support 100K+ Community
1
Joints RockJock Johnny Joint + poly bushing
Tubing 1.75" OD lowers / 1.50" OD uppers 5/16" wall DOM
https://jerdev.core4x4.com/web/image/product.template/27124/image_1920?unique=2385cda

16pc Kit

Master Rebuild kit for CMP-J-JL-K16
SKU: CMP-J-JL-K16-MRK
Does not fit Cadillac Escalade ESV

468.00 468.0 USD 468.00

468.00

Not Available For Sale

More ways to pay ▾

Select Color to see price and add to cart.

Lifetime warranty on all non-wear items United States

Made in USA Orem, Utah
Lifetime Guarantee Unconditional
10 Colors In-house powder coat
Fully Adjustable 0-6" of lift
3 X-Series Options Only Core 4x4

Product Details

Everything you need to refresh your suspension.

This rebuild kit includes all the essential components needed to replace common wear items and restore performance.

CE-9110RK × 4

CE-9110NRK × 2

CE-9112NRK × 8

BSH-CB-2892 × 4

BSH-CB-2891 × 2

BSH-CB-7087 × 6

Make Model Submodel Years
Jeep Wrangler 2018 - Present

Construction & Materials

Jeep Wrangler JL / JLU 18+ 16pc Camp Series Adjustable Control Arm, Track Bar, Steering, End Link Kit

Front Lower control arm built with 1.75” OD 5/16” Wall DOM. A Polyurethane Bushing on the fixed end and a Forged Johnny Joints on the adjustable end with 1.25” x 12 TPI - 2.625” long threads.

Front Upper control arm built with 1.5” OD 5/16” Wall DOM. Welded u-bracket on the welded end and a Forged Johnny Joints on the adjustable end with 1” x 14” TPI - 2.32” long threads.

Rear Lower control arm built with 1.75” OD 5/16” Wall DOM. A Polyurethane Bushing on the fixed end and a Forged Johnny Joints on the adjustable end with 1.25” x 12 TPI - 2.625” long threads.

Rear Upper control arm built with 1.5” OD 5/16” Wall DOM. Polyurethane Bushing on the fixed end and a Forged Johnny Joints on the adjustable end with 1” x 14” TPI - 2.32” long threads.

Front Track Bar built with 1.5” OD 5/16” Wall DOM. Polyurethane Bushing on the fixed end and a Forged Johnny Joints on the adjustable end with 1” x 14 TPI - 2.32” long threads.

Rear Track Bar built with 1.5” OD 5/16” Wall DOM. Polyurethane Bushing on the fixed end and a Forged Johnny Joints on the adjustable end with 1” x 14 TPI - 2.32” long threads.

Front Links built with .75” Cold Rolled Steel. Welded Johnny Joints on one fixed end and a Polyurethane Bushing on the other fixed end.

Rear End Links built with .75” Cold Rolled Steel. Welded Johnny Joints on one fixed end and a Polyurethane Bushing on the other fixed end.

Tie Rod and Drag Link made from 2" 7075 Aluminum. Tie Rod and Drag Link use Apex Chassis Forged Rod Ends.
