16pc Kit

Master Rebuild kit for CRS-J-JL-K16

392.00 392.0 USD 392.00

392.00

Not Available For Sale

More ways to pay ▾

100% bolt-on no welding Expert Support 100K+ Community
1
Joints Poly bushings
Tubing 1.875" OD lowers / 1.625" OD uppers 3/16" wall DOM
https://jerdev.core4x4.com/web/image/product.template/27108/image_1920?unique=2385cda

16pc Kit

Master Rebuild kit for CRS-J-JL-K16
SKU: CRS-J-JL-K16-MRK
Does not fit Chevrolet Suburban 1500

392.00 392.0 USD 392.00

392.00

Not Available For Sale

More ways to pay ▾

Select Color to see price and add to cart.

Lifetime warranty on all non-wear items United States

Made in USA Orem, Utah
Lifetime Guarantee Unconditional
10 Colors In-house powder coat
Fully Adjustable 0-6" of lift
3 X-Series Options Only Core 4x4

Product Details

Everything you need to refresh your suspension.

This rebuild kit includes all the essential components needed to replace common wear items and restore performance.

CE-9112NRK × 2

BSH-CB-2892 × 8

BSH-CB-2891 × 4

BSH-CB-2314 × 2

BSH-CB-7087 × 1

Make Model Submodel Years
Jeep Wrangler 2018 - Present

Construction & Materials

Jeep Wrangler JL / JLU 18+ 16pc Cruise Series Adjustable Control Arm, Track Bar, Steering, End Link Kit

Front Lower control arms built with 1.875” OD 3/16” Wall DOM. Polyurethane Bushings on the fixed and adjustable ends with 1.25” x 12 TPI - 3.25” long threads.

Front Upper control arms built with 1.625” OD 3/16” Wall DOM. Welded U-bracket on the fixed end and a Polyurethane Bushing on the adjustable end with 1” x 14 TPI - 3.25” long threads.

Rear Lower control arms built with 1.875” OD 3/16” Wall DOM. Polyurethane Bushings on the fixed and adjustable ends with 1.25” x 12 TPI - 3.25” long threads.

Rear Upper control arms built with 1.625” OD 3/16” Wall DOM. Polyurethane Bushings on the fixed and adjustable ends with 1” x 14 TPI - 3.25” long threads.

Front Track Bar built with 1.5” OD 5/16” Wall DOM. Polyurethane Bushing on the fixed end and a Forged Johnny Joints on the adjustable end with 1” x 14 TPI - 2.32” long threads.

Rear Track Bar built with 1.5” OD 5/16” Wall DOM. Polyurethane Bushing on the fixed end and a Forged Johnny Joints on the adjustable end with 1” x 14 TPI - 2.32” long threads.

Front End Links built with .75” Cold Rolled Steel. Polyurethane Bushings on both fixed ends.

Rear End Links built with .75” Cold Rolled Steel. Polyurethane Bushings on both fixed ends.

Tie Rod and Drag Link made from 2" 7075 Aluminum. Tie Rod and Drag Link use Apex Chassis Forged Rod Ends.
